Sandvik HSS-PM Blue Gun Nose PVD FeN coated Tap 1/4" UNC, DIN 2184-1 Short Body

Sandvik UNC 1/4-20 Spiral Point (Gun Nose) Tap – Premium Through-Hole Tapping (DIN 2184-1) Built for high-performance threading in steels and other demanding materials, this Sandvik UNC 1/4-20 spiral point...
$53.00
$53.00
(-0%)
Vendor: SANDVIK
SKU: T200-XM100DE-1/4 C145
Availability: In Stock
Subtotal: $53.00
Sandvik HSS-PM Blue Gun Nose PVD FeN coated Tap 1/4" UNC, DIN 2184-1 Short Body

Sandvik HSS-PM Blue Gun Nose PVD FeN coated Tap 1/4" UNC, DIN 2184-1 Short Body

$53.00

Sandvik HSS-PM Blue Gun Nose PVD FeN coated Tap 1/4" UNC, DIN 2184-1 Short Body

$53.00

Sandvik UNC 1/4-20 Spiral Point (Gun Nose) Tap – Premium Through-Hole Tapping (DIN 2184-1)

Built for high-performance threading in steels and other demanding materials, this Sandvik UNC 1/4-20 spiral point (gun nose) tap drives chips forward and out of the hole for clean, precise threads. The PVD FeN-coated HSS-PM substrate and DIN 2184-1 standard shank ensure long tool life, stability, and consistency. Best suited for through-hole applications.

Key Features & Benefits

  • Durable Cutting Edge – HSS-PM substrate with PVD FeN coating resists wear and heat for extended life.
  • Efficient Chip Evacuation – Spiral point geometry pushes swarf forward, ideal for through-hole tapping.
  • Reliable Standard – DIN 2184-1 shank design ensures robust performance in CNC and manual setups.
  • High Accuracy – Ground to 2B thread tolerance for repeatable, in-spec results.

Technical Specifications

Specification Metric Imperial
Thread Size UNC 1/4-20
Threads per Inch (TPI) 20
Thread Form UNC 60° UNC 60°
Thread Diameter 6.35 mm 0.25 in
Tap Chamfer Length 5.44 mm 0.2143 in
Premachined Hole Diameter 5.1 mm 0.2008 in
Premachined Hole Type / Hole Type Through hole Through hole
Thread Tolerance Class 2B 2B
Shank Standard DIN 2184-1 DIN 2184-1
Usable Length (LU) 30 mm 1.1811 in
Functional Length (LF) 80 mm 3.1496 in
Overall Length (OAL) 83 mm 3.2638 in
Neck Diameter 4.55 mm 0.1791 in
Flute Count 3
Flute Helix Angle 0° (spiral point)
Radial Rake Angle
Threading Length 14.1 mm 0.5551 in
Thread Back Taper Yes Yes
Threading Chamfer Type B = 3.5–5×TP (Gunnose)
Chip Breaker XM
Grade C145 C145
Substrate HSS-PM
Coating PVD FeN (iron-nitride)
Coolant Entry / Exit Without / None
Connection – Machine Side Tap shank DIN-metric 7.00 × 5.50
Connection Diameter (Machine Side) 7.0 mm 0.2756 in
Connection Diameter Tolerance h9
Weight 0.0236 kg 0.052 lb
Maximum Regrinds 0
Release Date 02/25/2014
Release Pack ID 14.1

Why Choose This Tool?

The Sandvik UNC 1/4-20 spiral point (gun nose) tap combines an HSS-PM substrate, wear-resistant FeN coating, and a DIN 2184-1 shank for exceptional durability and accuracy. Its efficient chip control and precision-ground threads make it an ideal solution for through-hole applications in steels and other challenging materials, whether in CNC machining or conventional setups.
